single detailIsolation Transformer

Isolation Transformer: An Isolation transformer is a transformer used to transfer electrical power from a source of alternating current.

Isolation Transformer

Volina is an ISO 9001-2015 certified company and the company is working as Isolation Transformer Manufacturers and provides the best Isolation Transformer in India . Isolation transformers are used to transfer electric power from alternating current (AC) power, achieved from a source, into some device or equipment while separating the powered tool from the source of power, done usually for safety purposes.

An ideal Isolation transformer eliminate impurities/harmonics to output supply and minimize potential difference between neutral to earth less than one volt .


isolation transformer , Three phase ,50 Hz , Copper wound , oil cooled , class of insulation B ,metallic body duly powder coated designed for input Voltage range 415+-5% and output voltage range 415+-5% ,Ratio 1:1 , Vector Group :Dyn 11, Delta- star , indoor /Outdoor type IP 42/55 with first filling of transformer oil of requisite dielectric strength up to level , efficiency more than 95 % , separate neutral bushing shall be brought out for earthing Potential difference between neutral to earth less the one volt with all standard fittings like digital temperature meter , adequate number of cooling radiators , lifting hooks one set , Earthing terminal two nos complete with Over load /short circuit protection .

  • • Output voltage -220,240VV in single phase 415,433 V in three phases or as per requirement
  • • Input voltage – 220,240V in single phase 415,433 V in three phases or as per requirement
  • • Ratio -1:1

Capacity: -

  • • 0.5 KVA to 15 KVA single phase
  • • 3KVA to 1500 KVA three phase
